Model

25
30
40
50
60

Motor Horsepower
25
30
40
50
60

Kilowatts
18.7
22.4
29.8
37.3
44.8

CFM at 100 PSI
105
125
180
215
265

M3/Min at 6.9 Bar
2.97
3.54
5.19
6.09
7.50

CFM at 125 PSI
100
115
160
200
244

M3/Min at 8.6
2.83
3.26
4.53
5.66
6.91

Air Connection
1-1/2" NPT
1-1/2" NPT
1-1/2" NPT
1-1/2" NPT
1-1/2" NPT

After Cooler Approach
10°F
10°F
12°F
15°F
16°F



Horsepower

25
30
40
50
60


L x W x H
(in.)

42 x 58 x 50
42 x 58 x 50
42 x 58 x 50
42 x 58 x 50
42 x 58 x 50

L x W x H
(cm.)
107 x 150 x 127
107 x 150 x 127
107 x 150 x 127
107 x 150 x 127
107 x 150 x 127


Horsepower

25
30
40
50
60


Weight (lbs.)

1700
1750
2100
2150
2200

Weight (kg.)
771
794
953
975
1000
